Product Details
FEATURES
Made with High-strength Steel: The pedal is machined with high-strength steel, giving superior quality and endurance.
Floor Mounted Organ Type Accelerator Pedal: The organ-type accelerator pedal allows the driver's foot and pedal to follow the same trajectory, making throttle control easier and more accurate.
High Precision Pressure Sensor with a Maximum Range of 75kg: The MOZA SR-P pedals utilize pressure sensors with a maximum range of 75KG. The pressure sensors detect the braking pedal stopping pressure, allowing users to obtain their ideal braking force by controlling the amount of pressure applied to the brake pedal.
16-bit High Precision Magnetic Encoder: The brake, clutch, and throttle pedals all use 16-bit precision magnetic encoders with 65,536 PPR resolution, providing higher resolution and greater stability than a Hall sensor.
Dual Sensor Fusion Algorithm: The brake utilizes both a pressure sensor and angle sensor, allowing for fine-tuned braking. The initial stage is dominated by the angle sensor, allowing racers to control the braking angle, while the middle and final stages are controlled by the pressure sensor for easier pedal control.
Braking Spring and Damping Block Combined: Utilizing both a braking spring and damping block, racers can enjoy more control during the initial stage of pedal travel, with increased stiffness in the final stages of braking to closely simulate the feel of a real brake pedal.
Direct Connection with PC Through USB Port: The MOZA SR-P pedals can connect to a PC easily through a USB port and be calibrated using the MOZA Pit House software. Compatible with all sim racing gear on the market.
Multiple Use Scenarios: The anti-slip mat on the bottom prevents the pedals from slipping when used without professional brackets, while also allowing them to be easily integrated into more advanced setups.
Detachable Pedal Design: The pedals can be detached and mounted onto other professional brackets with ease. For hardcore users, the pedals can also be reversed.
Pedal Output Curve Adjustment: MOZA Pit House allows for easy configuration of the pedal output curves according to different needs.
SPECIFICATIONS
- Material: High-strength steel
- Plate Material: CNC Aluminum Alloy
- Color: Black
- Braking Sensor: Pressure sensor + angle sensor
- Max Range of Pressure Sensor: 75KG
- Throttle Sensor: Angle sensor
- Clutch Sensor: Angle sensor
- Angle Sensor Resolution: 16-bit (65,536 PPR)
- Pedal Spacing: Adjustable
- Pedal Surface Height: Adjustable
- Pedal Connection Port: USB direct
- Pedal Travel Software Adjustment: Yes
- Pedal Travel Reverse Function: Yes
- Anti-Slipping Bottom: Yes
USER MANUAL
WARRANTY
MOZA Racing warranty covers all defects in materials and workmanship for all products sold by MOZA Racing. Only original, unaltered, and unmodified materials and workmanship are covered by this policy. This warranty does not cover damage caused by improper deployment, misuse, accidents, neglect, or the natural breakdown of materials over time. Products should be returned to us for evaluation. Items with defects in materials and workmanship will be repaired, exchanged, or refunded. For more information about repair, exchange, and returns, please visit the website's after-service policy.
